Our standard Pass & Seymour® combination switches allow you to add lights to any room in your home without having to add or replace wall boxes. Tamper-resistant version features dual mechanical shutter system to help prevent insertion of foreign objects.
Pass & Seymour® Combination Switch/Receptacle, 3-Way Double Grounding, 15 A, 120/277 VAC Electrical Rating, 2 Pole, Toggle Actuator, NEMA WD-1/WD-6 Enclosure, Wall Mounting, 1.32 in L x 0.94 in W x 4.06 in H Size, 30000 Cycles Operating Cycles, Environmental Conditions: -30 to 60 deg C Operating Temperature, Thermoplastic, Ivory
| Actuator | : | Toggle |
| Color | : | Ivory |
| Enclosure | : | NEMA WD-1/WD-6 |
| Environmental Conditions | : | -30 to 60 deg C Operating Temperature |
| Material | : | Thermoplastic |
| Mounting | : | Wall |
| Operating Cycles | : | 30000 Cycles |
| Size | : | 1.32 in L x 0.94 in W x 4.06 in H |
| Type | : | 3-Way Double Grounding |
| Electrical Ratings | : | 15 A, 120/277 VAC |
| Number of Poles | : | 2 |
- Easily accessible break-off separate or common feed
- Side wire 12 and 14 AWG
- 2-devices fit into the space of one
- Grounding combination devices meet NEC requirements
- Long-life red neon lamp in pilot light rated 1/25 W, 125V
- Tamper-resistant version features dual mechanical shutter system to help prevent insertion of foreign objects
Instruction/Installation Manual
