EATON 1004428ACH
EATON Cutler-Hammer 1004428ACH 3-Wire Multi-Position Residential Service Single Meter Socket With Horn Bypass, 600 VAC, 100 A, 1 Phase
- Manufacturer Name: Eaton
- MPN: 1004428ACH
- Brand Name: EATON
- UPC: 782116123391
- FEPN: 1004428ACH EC
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
EATON line of 1-position, self contained meter sockets house the utilities electrical watt hour meters in residential and commercial buildings. Choose from the widest range of utility approved sockets in the industry, including 100 to 320 A units and designs such as ring less, bypass and more.
EATON Cutler-Hammer Single Meter Socket, 3-Wire Multi-Position Residential Service, 600 VAC, 100 A, 1 ph, Overhead/Underground Feed, 4 Jaws, 6 AWG to 250 kcmil, 8 to 2/0 AWG Wire, Small Open Hub, Ring Cover, Line/Load Terminal, 4.5 in L x 40.63 in W x 14.13 in H Dimensions
| Cover Type | : | Ring |
| Dimensions | : | 4.5 in L x 40.63 in W x 14.13 in H |
| Feed Type | : | Overhead/Underground |
| Hub Type | : | Small Open |
| Number of Jaws | : | 4 |
| Terminal Type | : | Line/Load |
| Type | : | 3-Wire Multi-Position Residential Service |
| Wire Size | : | 6 AWG to 250 kcmil, 8 to 2/0 AWG |
| Voltage Rating | : | 600 VAC |
| Amperage Rating | : | 100 A |
| Phase | : | 1 |
- Block assembly base exceeds 400 in-lb of torque
- 1-piece, die-run enclosure
- High visibility EATON name embossed on cover
- Knockouts are installer friendly
- Oversized 7/8 in Dia, heavy duty, steel lug screws
- Slide nuts are captive
- Horn bypass kit is field installable by changing out slide nut
- Integral triplex or quadplex ground extruded in neutral lug
- 100% plated bridge with 4-point mounting
- KAIC rating up to 200 kAIC rating with specified overcurrent protection devices
- Provides a complete EATON residential solution
- Copper plated alloy jaws with reinforcing spring
- 6 AWG to 250 kcmil line, 8 to 2/0 AWG load
