Wiring Device-Kellems HBL24CM13
Wiring Device-Kellems Twist-Lock® Insulgrip® HBL24CM13 Heavy Duty Isolated Grounding Standard Sized Cord Mount Female Connector, 125/250 VAC, 20 A, 3 Poles, 4 Wires, Yellow
- Manufacturer Name: Hubbell
- MPN: HBL24CM13
- Brand Name: Wiring Device-Kellems
- UPC: 783585038483
- FEPN: HBL24CM13 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Twist-Lock® Insulgrip® Female Connector, Heavy Duty Isolated Grounding Standard Sized Cord Mount, 125/250 VAC, 20 A, 2 hp, 3 Pole, 4 Wires, L14-20R/WD1/WD5 NEMA Rating, Industrial/Marine Grade, IP20 Enclosure, 0.35 to 1.15 in Diameter Cord, -40 to 75 deg C, Pressure Screw Terminal, Nylon, Yellow, 2.33 x 2.33 x 3.86 in
| Cord Diameter | : | 0.35 to 1.15 in |
| Dimensions | : | 2.33 x 2.33 x 3.86 in |
| Enclosure | : | IP20 |
| Grade | : | Industrial/Marine |
| Horsepower | : | 2 hp |
| Material | : | Nylon |
| NEMA Rating | : | L14-20R/WD1/WD5 |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Pressure Screw |
| Type | : | Heavy Duty Isolated Grounding Standard Sized Cord Mount |
| Voltage Rating | : | 125/250 VAC |
| Amperage Rating | : | 20 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | Yellow |
- Ribbed nylon housing provides a secure grip and impact and chemical resistance
- Superior cord grip design for flat cable protects terminations from excess strain
- Integral dust shield protects wiring chamber from dust or contaminants
- Corrosion resistant
