Wiring Device-Kellems HBL15W47A
Wiring Device-Kellems HBL15W47A Female Grounding Insulated Watertight Cord Mount Straight Blade Connector, 125 VAC, 15 A, 2 Poles, 3 Wires, Yellow
- Manufacturer Name: Hubbell
- MPN: HBL15W47A
- Brand Name: Wiring Device-Kellems
- UPC: 783585131276
- FEPN: HBL15W47A HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL15W47A, Straight Blade Connector, Female Grounding Insulated Watertight Cord Mount, 125 VAC, 15 A, 1/2 hp, 2 Pole, 3 Wires, 5-15R NEMA Rating, Commercial/Industrial Grade, NEMA 4/4X/6/6P/12 Enclosure, 3/8 to 5/8 in Diameter Cord, -40 to 60 deg C, Screw Terminal, Elastomer/Composite, Yellow, 1.85 in Dia x 4.42 in L Dimensions
| Cord Diameter | : | 3/8 to 5/8 in |
| Dimensions | : | 1.85 in Dia x 4.42 in L |
| Enclosure | : | NEMA 4/4X/6/6P/12 |
| Grade | : | Commercial/Industrial |
| Horsepower | : | 1/2 hp |
| Material | : | Elastomer/Composite |
| NEMA Rating | : | 5-15R |
| Temperature Rating | : | -40 to 60 deg C |
| Terminal Type | : | Screw |
| Type | : | Female Grounding Insulated Watertight Cord Mount |
| Voltage Rating | : | 125 VAC |
| Amperage Rating | : | 15 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | Yellow |
- Smooth body design minimizes collection points simplifying thewash down process
- Strain relief nut always seals on the body, minimizing debris collection
- Stainless steel hardware and corrosion-resistant connection points
