High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.
Bussmann High Speed Fuse, North American Style, Series: FWX, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 50 A, 600 V, 50/200 kA Interrupt, Blade Terminal, Flush/Stud Mount, Cartridge Body Type, Single Element, Ceramic, 0.81 in Dia x 3.19 in L Body Size
| Body Size | : | 0.81 in Dia x 3.19 in L |
| Element | : | Single |
| Indicating/Non-Indicating | : | Non-Indicating |
| Material | : | Ceramic |
| Mounting Type | : | Flush/Stud |
| Rejection/Non-Rejection | : | Non-Rejection |
| Series | : | FWX |
| Terminal Type | : | Blade |
| Type | : | North American Style |
| Amperage Rating | : | 50 A |
| Voltage Rating | : | 600 V |
| Interrupt Rating | : | 50/200 kA |
| Body Type | : | Cartridge |
- Low arc voltage and low energy let through
- Excellent DC performance
- Low watts loss
- Superior cycling capability
- North American style bolted tags and flush end high speed fuses
