Wiring Device-Kellems HBL2436
Wiring Device-Kellems HBL2436 HBL® 3-Phase Flanged Grounding Single Screw Mount Locking Receptacle, 480 VAC, 20 A, 3 Poles, 4 Wires, White
- Manufacturer Name: Hubbell
- MPN: HBL2436
- Brand Name: Wiring Device-Kellems
- UPC: 783585038346
- FEPN: HBL2436 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL2436, Locking Receptacle, 3-Phase Flanged Grounding Single Screw Mount, Series: HBL®, 480 VAC, 20 A, 5 hp, 3 Pole, 4 Wires, L16-20R NEMA Rating, Industrial Grade, NEMA 4X/12/IP44 Enclosure, -40 to 75 deg C, Screw Terminal, Nylon, White, 3.06 x 3.06 x 2.27 in Dimensions
| Dimensions | : | 3.06 x 3.06 x 2.27 in |
| Enclosure | : | NEMA 4X/12/IP44 |
| Grade | : | Industrial |
| Horsepower | : | 5 hp |
| Material | : | Nylon |
| NEMA Rating | : | L16-20R |
| Series | : | HBL® |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 3-Phase Flanged Grounding Single Screw Mount |
| Voltage Rating | : | 480 VAC |
| Amperage Rating | : | 20 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | White |
- Backwired terminations for ease of installation
