Panduit® Pan-Term™ Ring Terminal, Type PNF-R, Solid/Stranded Conductor, 14 AWG Conductor, 1/4 in Stud, 1.06 in Length, Brazed Seam/Funnel Entry/Seamed/Internal Serration Barrel, Ring Tongue, 0.46 in W x 0.03 in THK Tongue, 600 V, Specifications: 0.162 in Dia Nylon Insulation, 0.21 in Mounting Hole Size, 0.4 in Clearance, 7/32 in L Wire Strip, Ring Shape Enclosure, 221 deg F, Copper, Tin Plated, Blue

• Insulug type YAE-N nylon insulated terminals are designed with a multi-finger insulation grip for paper, EPR and other elastic or hard to grip insulations
• EPR and other elastic or hard to grip Insulations
• The metal fingers firmly grip the insulation providing superior holding characteristics, cable support and strain relief
• Type YAE-N terminals are rated 105 deg C and meet military standard AS25036 Class 2 and SAE-AS7928 requirements
• Multi-finger insulation grip - Provides superior insulation holding characteristics
• Especially on epr and other elastic-type insulations
• Brazed seam provides stronger more durable termination
• Manufactured of pure electrolytic copper provides maximum conductivity, low resistance and ductility for excellent crimp forming properties, deep V groove
• Inner barrel serrations, provide optimum conductivity, reliability and holding power, smooth funnel entry - easy wire insertion

• Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_PNF14-4R-M_Full_Engineering_Drawing.pdf
