Blackburn® is a complete and reliable line of overhead, grounding, mechanical and compression connectors that respond to a broad range of construction needs.
Blackburn® Compression Splice, Type CSP, Copper Conductor, 500 kcmil Conductor, 2-3/4 in Length, Short Barrel, 35 kV, Copper, Brown, Tin Plated
| Conductor Type | : | Copper |
| Finish | : | Tin Plated |
| Type | : | Type CSP |
| Voltage Rating | : | 35 kV |
| Conductor Size | : | 500 kcmil |
| Length | : | 2-3/4 in |
| Barrel Type | : | Short |
| Material | : | Copper |
| Color | : | Brown |
- Made of high conductivity seamless copper tubing, tin plated for corrosion-resistance
- Specifically chamfered barrel for ease of installation
- Color coded for matching die identification
- Can be used for medium voltage application up to 35 kV provided proper insulation techniques are used
- For use with copper conductor AWG, stranded, flexible cable, welding cable and portable cord
