Color-Keyed® 60930
Color-Keyed® 60930 Reducing Splice Connector, 2 AWG, 1/0 AWG Aluminum/Copper Conductor, Die Code: 50, 2.38 in L, Aluminum
- Manufacturer Name: ABB
- MPN: 60930
- Brand Name: Color-Keyed®
- UPC: 786210609300
- FEPN: 60930 TB
- Min Order Qty: 1
- Quantity Interval: 10
-
Inventory Availability
-
Retail Price:
The Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by T&B®. When using the Color-Keyed® compression system with our Blackburn® line of compression connectors, the installer can count on a reliable, high quality connection.
Color-Keyed® Reducing Splice Connector, Aluminum/Copper Conductor, 2 AWG, 1/0 AWG Conductor, Die Code: 50, 2.38 in Length, 600 V AC, 90 deg C, Aluminum, Tin Plated, Tan, 0.63 in Dia
| Color | : | Tan |
| Dimensions | : | 0.63 in Dia |
| Finish | : | Tin Plated |
| Temperature Rating | : | 90 deg C |
| Voltage Rating | : | 600 V AC |
| Conductor Size | : | 2 AWG, 1/0 AWG |
| Conductor Type | : | Aluminum/Copper |
| Die Code | : | 50 |
| Length | : | 2.38 in |
| Material | : | Aluminum |
- Designed for the right combination of equivalent sizes
- For 90 deg C certified to 600 VAC and recommended up to 35 kVAC applications
- Filled with high temperature oxide inhibiting compound
- 2 to 1/0 AWG copper/aluminum wire
Specification Sheet
