Wiring Device-Kellems HBL20443
Wiring Device-Kellems HBL20443 HBL® Multi-Phase Grounding Heavy Duty Single Screw Mount Locking Receptacle, 480 VAC, 30 A, 3 Poles, 4 Wires, Black/Red
- Manufacturer Name: Hubbell
- MPN: HBL20443
- Brand Name: Wiring Device-Kellems
- UPC: 783585017419
- FEPN: HBL20443 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL20443, Locking Receptacle, Multi-Phase Grounding Heavy Duty Single Screw Mount, Series: HBL®, 480 VAC, 30 A, 3 Pole, 4 Wires, Industrial Grade, NEMA 4/4X/12/IP20 Enclosure, -40 to 75 deg C, Screw Terminal, Thermoplastic, Black/Red, 3.28 x 1.94 x 1.75 in Dimensions
| Dimensions | : | 3.28 x 1.94 x 1.75 in |
| Enclosure | : | NEMA 4/4X/12/IP20 |
| Grade | : | Industrial |
| Material | : | Thermoplastic |
| Series | : | HBL® |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | Multi-Phase Grounding Heavy Duty Single Screw Mount |
| Voltage Rating | : | 480 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | Black/Red |
- Spring loaded safety shutter contains arcing when mating or un-mating devices under load
- Box terminals in conjunction with screws with pressure pads provide maximum termination strength and dependability
- Thermoset molded housing provides maximum heat resistance
Specification Sheet
