Wiring Device-Kellems FR480BKA
Wiring Device-Kellems FR480BKA Standard Pedestal Service Fitting, 78 cu-in Capacity, For Use With PT27A/PT7XC Through Floor Fitting, Fire Rated Poke Through, Composite
- Manufacturer Name: Hubbell
- MPN: FR480BKA
- Brand Name: Wiring Device-Kellems
- UPC: 783585396194
- FEPN: FR480BKA HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, FR480BKA, Standard Pedestal Service Fitting, Direct into Device Cable Entry, 9.03 in Length, 5.45 in Width, 2.79 in Depth, For Use With: PT27A/PT7XC Through Floor Fitting, Fire Rated Poke Through, Floor Mounting, 78 cu-in Capacity, Composite, Yellow, Epoxy Coated
| Cable Entry Size | : | Direct into Device |
| Color | : | Yellow |
| Depth | : | 2.79 in |
| Finish | : | Epoxy Coated |
| Length | : | 9.03 in |
| Mounting Type | : | Floor |
| Type | : | 1-Phase Corrosion Resistant Grounding Male Standard Cord Mount |
| Width | : | 5.45 in |
| Capacity | : | 78 cu-in |
| Suitable For Use With | : | PT27A/PT7XC Through Floor Fitting, Fire Rated Poke Through |
| Material | : | Composite |
- Fabricated construction
- 14 hr fire rating (13 hr for steel floor units and concrete topping, D900 Series Design)
Line Drawing
