Wiring Device-Kellems HBL23CM10
Send Print
  1. pin-int

Wiring Device-Kellems HBL23CM10

Wiring Device-Kellems Twist-Lock® HBL23CM10 1-Phase Flush Mount Grounding Single Screw Mount Corrosion-Resistant Locking Receptacle, 125 VAC, 30 A, 2 Poles, 3 Wires, Yellow

  • Manufacturer Name: Hubbell
  • MPN: HBL23CM10
  • Brand Name: Wiring Device-Kellems
  • UPC: 783585808147
  • FEPN: HBL23CM10 HW
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Wiring Device-Kellems Twist-Lock® Locking Receptacle, 1-Phase Flush Mount Grounding Single Screw Mount Corrosion-Resistant, 125 VAC, 30 A, 1 hp, 2 Pole, 3 Wires, L5-20R NEMA Rating, IP20 Enclosure, -40 to 75 deg C, Screw Terminal, Nylon, Yellow, 3.28 x 1.73 x 1.23 in

Dimensions       :      3.28 x 1.73 x 1.23 in
Enclosure       :      IP20
Horsepower       :      1 hp
Material       :      Nylon
NEMA Rating       :      L5-20R
Temperature Rating       :      -40 to 75 deg C
Terminal Type       :      Screw
Type       :      1-Phase Flush Mount Grounding Single Screw Mount Corrosion-Resistant
Voltage Rating       :      125 VAC
Amperage Rating       :      30 A
Number of Poles       :      2
Number of Wires       :      3
Color       :      Yellow
  • 0.04 in brass terminal clamp material
  • #10-32 bronze (white finish on neutral screw when used) terminal screw
  • 0.04 in brass contact spring, ground contact and back plate
  • Black nylon cover (top), nylon polyester base
  • 0.05 in brass bridge mounting strap
  • Brass rivet, stainless steel auto ground clip
  • Molded in or stamped on ratings
  • Permanently ink marked on product catalog number
  • Withstand 2000 VAC minimum dielectric voltage
  • Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150 Percent of rated current at a power factor of 0.75
  • 20 A 12 AWG terminal accommodation
  • Terminals identified in accordance with UL498 (x, y, z, white, green)
  • Wire restraint recess for both back and side wiring, greatly reduces the possibility of loosening the terminal connection
  • Face color coding by voltage facilitates locating and mating of proper devices
  • Nickel plated brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device-Kellems_HBL23CM10_Installation_Manual.pdf
  • pdfLine Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device-Kellems_HBL23CM10_Line_Drawing.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device-Kellems_HBL23CM10_Specification_Sheet.pdf
  • pdfWarranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device-Kellems_IG8362SA_Warranty.pdf
  • linkVIDEO LINK https://youtu.be/1DnPJu3QNw0
