EATON HFD2020WA05D01
EATON HFD2020WA05D01 C Series Type HFD Molded Case Circuit Breaker, 600 VAC/250 VDC, 20 A, 65/100 kA Interrupt, 2 Poles, Fixed Thermal/Fixed Magnetic Trip
- Manufacturer Name: Eaton
- MPN: HFD2020WA05D01
- Brand Name: EATON
- UPC: 786679087824
- FEPN: HFD2020WA05D01 EC
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
EATON series C molded case circuit breakers are used in panelboard, switchboard, motor control center and busway applications for dependable branch circuit protection. They have proven user acceptance for over 20 years and meet or exceed North American standards. Available for systems up to 600 VAC/250 VDC with current ratings up to 2500 A.
EATON Molded Case Circuit Breaker, Type HFD, Series: C Series, 600 VAC/250 VDC, 20 A, 50/60 Hz, 65/100 kA Interrupt, F Frame, Fixed Thermal/Fixed Magnetic Trip, 2 Pole, Line/Load, 1A-1B Auxiliary, Surface Mount, 40 deg C, 3.38 x 2.75 x 6 in, Glass Polyester
| Auxiliary Contact Rating | : | 1A-1B |
| Connection Type | : | Line/Load |
| Dimensions | : | 3.38 x 2.75 x 6 in |
| Frame | : | F |
| Frequency Rating | : | 50/60 Hz |
| Material | : | Glass Polyester |
| Mounting Type | : | Surface |
| Series | : | C Series |
| Temperature Rating | : | 40 deg C |
| Type | : | Type HFD |
| Voltage Rating | : | 600 VAC/250 VDC |
| Amperage Rating | : | 20 A |
| Interrupt Rating | : | 65/100 kA |
| Number of Poles | : | 2 |
| Trip Type | : | Fixed Thermal/Fixed Magnetic |
- Patented contact design features high speed "blow-open" action, resulting in superior performance
- Without terminals
- 100 kA at 240 VAC, 65 kA at 480 VAC interrupt rating
