T&B® Compression Connector, Insulated, 1 in, 1-11/16 in Dia, For Use With: EMT Conduits, Steel, Chromate Coated/Electro-Zinc Plated, 1-7/8 in L
| Diameter | : | 1-11/16 in |
| Dimensions | : | 1-7/8 in L |
| Type | : | Insulated |
| Trade Size | : | 1 in |
| Suitable For Use With | : | EMT Conduits |
| Material | : | Steel |
| Finish | : | Chromate Coated/Electro-Zinc Plated |
- Rugged all steel construction
- Nylon insulator firmly secured in place-protects conductors, reduces wire pulling effort and prevents thread damage in handling
- Thermoplastic insulator
- Rain tight construction
- Rings designed to positively bond conduit to fitting
- Unique locknut design provides effective bond between fitting and box or enclosure, ground continuity is assured
