Sta-Kon® wire terminals offer more copper and a wider funnel to assure premium connection with less work in a line that includes insulated and non-insulated terminals, splices, wire joints, disconnects, ferrules, heat shrinkable terminals, splices and disconnects.
Sta-Kon® Parallel Splice, Insulated, 22 to 20 AWG Conductor, 0.2 in OD Barrel, 0.84 in Length, 600 V AC, 105 deg C, Copper, Red, Tin Coated, 0.2 in W Dimensions
| Color | : | Red |
| Dimensions | : | 0.2 in W |
| Finish | : | Tin Coated |
| Temperature Rating | : | 105 deg C |
| Type | : | Insulated |
| Voltage Rating | : | 600 V AC |
| Conductor Size | : | 22 to 20 AWG |
| Barrel Outer Diameter | : | 0.2 in |
| Length | : | 0.84 in |
| Material | : | Copper |
- Wires are laid side by side in the connector and the splice connection is complete in One-crimp
- Offer advantages in simplicity of installation and small size
- One-crimp completes the splice
- Nylon insulated
