nVent HOFFMAN WS242008SS
nVent HOFFMAN WATERSHED™ WS242008SS WS1 Enclosure, 24 in L x 20 in W x 8 in D, NEMA 4X NEMA Rating, 304 Stainless Steel
- Manufacturer Name: nVent
- MPN: WS242008SS
- Brand Name: nVent HOFFMAN
- UPC: 783510131135
- FEPN: WS242008SS HE
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Specifically designed for use in sanitary washdown production environments, particularly food and beverage manufacturing. Hoffman WaterShed Enclosures feature a sloped top, sloped door edges, bullet-style hinges and additional unique features that facilitate washdown runoff.
nVent HOFFMAN WATERSHED™ Enclosure, Series: WS1, 24 in Length, 20 in Width, 8 in Depth, NEMA 4X, Bullet Hinged/Lift-Off Cover, Lock: Quarter Turn Latch, Wall Mount, 304 Stainless Steel, Brushed
| Cover Type | : | Bullet Hinged/Lift-Off |
| Finish | : | Brushed |
| Lock | : | Quarter Turn Latch |
| Mounting Type | : | Wall |
| Series | : | WS1 |
| Length | : | 24 in |
| Width | : | 20 in |
| Depth | : | 8 in |
| NEMA Rating | : | NEMA 4X |
| Material | : | 304 Stainless Steel |
- Seams continuously welded and ground smooth
- Smooth type 304 stainless steel lift-off bullet-style hinges
- Hinges are shielded by door
- Hinged side of door has provisions to allow direct flushing of hinge area
- 20 deg sloped top facilitates runoff of water and cleaning solutions and prohibits the placement of objects on the top of the enclosure
- 170 deg door opening
- Door edges are sloped 20 deg at top and bottom edges to facilitate runoff
- Stainless steel quarter-turn latches furnished with flush slotted insert
- Seamless foam in place gasket
- Self-grounding latch system with double seal
- Bonding provision on door, grounding stud on body
- Furnished hardware kit consists of panel mounting fasteners, grounding hardware and sealing washers for wall mounting holes
