BUCHANAN 2006SB
BUCHANAN 2006SB Splice Cap Crimp Connector, 18 to 10 AWG Solid Copper Wire, Non-Insulated Insulation, Copper
- Manufacturer Name: Ideal Industries
- MPN: 2006SB
- Brand Name: BUCHANAN
- UPC: 781789452913
- FEPN: 2006SB II
- Min Order Qty: 1000
- Quantity Interval: 1000
-
Inventory Availability
-
Retail Price:
Crimp connectors from IDEAL® are designed for making fast, permanent, pressure-type connections. Whether there is a connection in a high vibration environment or installations at an OEM, there is a solution available. The steel and copper crimp connectors cover a wide range of combinations and have available insulating caps to protect against dangerous electrical shock.
BUCHANAN Crimp Connector, Splice Cap, Solid Copper Wire, 18 to 10 AWG Wire, Non-Insulated Insulation, 600 VAC, Specifications: (2) 18 AWG Minimum, (4) 12 AWG Max Wire Combination, Copper
| Specifications | : | (2) 18 AWG Minimum, (4) 12 AWG Max Wire Combination |
| Type | : | Splice Cap |
| Voltage Rating | : | 600 VAC |
| Wire Size | : | 18 to 10 AWG |
| Wire Type | : | Solid Copper |
| Insulation Type | : | Non-Insulated |
| Material | : | Copper |
- Solid copper sleeve require less crimping pressure and resist corrosion in harsh environments
- Designed for making fast, permanent, pressure-type connections
RoHS
