EATON 10250T line of 30.5 mm pushbuttons features a heavy duty zinc die-cast construction. Reliability nibs improve contact reliability even under dry circuit and fine dust conditions. In addition, drainage holes prevent the build-up of liquid inside the operator, which can prevent operation in freezing environments.

EATON Illuminated Pushbutton, Heavy Duty Oil/Watertight Standard Square, Series: 10250T, 30.5 mm Size, 1NO-1NC Contact Configuration, Momentary Contact Mode, 10 A at 600 VAC, 5 A at 250 VDC Contact, Incandescent Lamp, Legend: POWER ON, Bezel/Housing: Polished Chrome Bezel, Extended Button Actuator, NEMA 3/3R/4/4X/12/13/IP65 Enclosure, Die-Cast Zinc, Polished Chrome, Red, Environmental Conditions: 10 to 150 deg F Operating Temperature, 95% Relative Humidity at 60 deg C

• Heavy duty die-cast zinc construction
• Enclosed silver contacts with reliability nibs
• Diaphragm seals with drainage holes
• Grounding nibs on the operator casing
• 120 V transformer incandescent light unit
