Pass & Seymour® Combination Switch/Receptacle, 3-Way Grounding, 120/125 VAC, 15 A, Neon Lamp, 1/25 W Lamp, 1NO Contact Configuration, Wall Mounting, Side Wire Terminal, -30 to 60 deg C, Thermoplastic, Ivory, 1.32 in L x 0.94 in W x 4.06 in H Dimensions
| Color | : | Ivory |
| Contact Configuration | : | 1NO |
| Dimensions | : | 1.32 in L x 0.94 in W x 4.06 in H |
| Lamp Type | : | Neon |
| Lamp Wattage | : | 1/25 W |
| Material | : | Thermoplastic |
| Mounting | : | Wall |
| Temperature Rating | : | -30 to 60 deg C |
| Terminal Type | : | Side Wire |
| Type | : | 3-Way Grounding |
| Voltage Rating | : | 120/125 VAC |
| Amperage Rating | : | 15 A |
- Easily accessible break-off separate or common feed
- 2-devices fit into the space of one
- Side wire 12 and 14 AWG
- Tamper-resistant version features dual mechanical shutter system to help prevent insertion of foreign objects
- Grounding combination devices meet NEC requirements
- Toggle actuator
Instruction/Installation Manual
