RadioRA® 2 Maestro® RRD-6D-WH
RadioRA® 2 Maestro® RRD-6D-WH Local Control Dimmer, 120 VAC, 1 Poles, On/Off Operation, White
- Manufacturer Name: Lutron
- MPN: RRD-6D-WH
- Brand Name: RadioRA® 2 Maestro®
- UPC: 027557771559
- FEPN: RRD-6D-WH LU
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
RadioRA® 2® 2 Maestro® local controls include a front accessible service switch (FASSTM) for safe lamp replacement. RadioRA® 2® 2 Maestro® local controls install in single-pole or multi-location applications. Remote dimmers/switches are available for multi-location control.
RadioRA® 2 Maestro® Local Control Dimmer, Series: RRD-6D, 120 VAC, 600 VA Power, 50/60 Hz Frequency, 1 Pole, Magnetic Low Voltage Lamp, Operation Mode: On/Off, Wall Mounting, 0 to 40 deg C, White, 4-11/16 in H x 2-15/16 in W x 5/16 in D Dimensions
| Dimensions | : | 4-11/16 in H x 2-15/16 in W x 5/16 in D |
| Frequency Rating | : | 50/60 Hz |
| Lamp Type | : | Magnetic Low Voltage |
| Mounting Type | : | Wall |
| Power Rating | : | 600 VA |
| Series | : | RRD-6D |
| Temperature Rating | : | 0 to 40 deg C |
| Voltage Rating | : | 120 VAC |
| Number of Poles | : | 1 |
| Operation Mode | : | On/Off |
| Color | : | White |
- On a single tap, lights fade on/off
- On a double tap, lights go to full on
- When on, press and hold the tapswitch to engage the delayed long fade to off
- Light levels can be fine-tuned by pressing and holding the dimming rocker until the desired light level is reached
- 0 to 90% humidity
- Non-condensing
- ESD protection tested to withstand electrostatic discharge without damage or memory loss, in accordance with IEC 61000-4-2
- 600 W for incandescent/halogen
