Hubbell® USB chargers are available in the new type C port, a combination unit with type A and C and the legacy type A, all with more power. The increase in power to a 5 amp 5 VAC USB port adds capacity so that there is always ample current to support multiple device charging. Portable mobile manufacturers are using the faster type C ports. More phones, tablets and other electronic devices are expected to use this new standard.

Wiring Device-Kellems tradeSELECT® USB Charger Receptacle, Duplex Grounding Heavy Duty Standard Tamper-Resistant, 125 V, 15 A, 1875 W Electrical Rating, 1 ph, 2 Pole, 3 Wires, 14 to 12 AWG Wire, Type-A USB 2.0/C USB, 1 USB Quantity, 5 A, 5 VDC USB, 1.75 in W x 1.82 in D x 3.28 in H Size, Screw Terminal Connection, Commercial Grade, Composite, White, Environmental Conditions: -40 to 75 deg C Operating, NEMA 5-15R Enclosure

• USB type C port is legacy USB type A compatible
• Heavy duty stainless steel USB ports, rated for minimum 10000 cord insertions and removals
• Patented Hubbell® tamper-resistant technology uses cam action shutters
• High Power 5 A, 5 V USB Output

• Warranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device-Kellems_IG8362SA_Warranty.pdf
• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device-Kellems_USB15A5W_Installation_Manual.pdf
• Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device-Kellems_USB15AC5W_Specification_Sheet.pdf
• Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device-Kellems_USB15AC5_Line_Drawing.pdf
