EATON HT800 Series features a wide variety of devices, including momentary, illuminated and mushroom head pushbuttons, selector switches, indicating lights and push-pull switches. They are corrosion-resistant and water- and oil-tight devices that are suitable for industrial applications, including replacement of other manufacturer's 30.5 mm pushbutton devices.
EATON Illuminated Indicating Light, Full Voltage Momentary Standard Oiltight Watertight, Series: HT800, 24 VAC/VDC, White Lens, Incandescent Lamp, Bezel/Housing: Polished Chrome, 30.5 mm Size, Flat/Round Shape, Screw Terminal, NEMA 3/3R/4/4X/12/13 Enclosure, Environmental Conditions: 10 to 140 deg F Operating, -40 to 176 deg F Storage, 95% RH at 60 deg C Humidity
| Bezel/Housing | : | Polished Chrome |
| Enclosure Type | : | NEMA 3/3R/4/4X/12/13 |
| Environmental Conditions | : | 10 to 140 deg F Operating, -40 to 176 deg F Storage, 95% RH at 60 deg C Humidity |
| Lamp Type | : | Incandescent |
| Lens Color | : | White |
| Series | : | HT800 |
| Shape | : | Flat/Round |
| Size | : | 30.5 mm |
| Terminal Type | : | Screw |
| Type | : | Full Voltage Momentary Standard Oiltight Watertight |
| Voltage Rating | : | 24 VAC/VDC |
