Wiring Device-Kellems HBL2526
Wiring Device-Kellems Twist-Lock® Insulgrip® HBL2526 3-Phase Flanged Grounding Single Standard Screw Mount Locking Receptacle, 277/480 VAC, 20 A, 4 Poles, 5 Wires, White
- Manufacturer Name: Hubbell
- MPN: HBL2526
- Brand Name: Wiring Device-Kellems
- UPC: 783585038643
- FEPN: HBL2526 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Twist-Lock® Insulgrip® Locking Receptacle, 3-Phase Flanged Grounding Single Standard Screw Mount, 277/480 VAC, 20 A, 5 hp, 4 Pole, 5 Wires, L22-20R NEMA Rating, Industrial Grade, IP20 Enclosure, -40 to 75 deg C, Screw Terminal, Nylon, White, 3.06 x 3.06 x 2.27 in
| Dimensions | : | 3.06 x 3.06 x 2.27 in |
| Enclosure | : | IP20 |
| Grade | : | Industrial |
| Horsepower | : | 5 hp |
| Material | : | Nylon |
| NEMA Rating | : | L22-20R |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 3-Phase Flanged Grounding Single Standard Screw Mount |
| Voltage Rating | : | 277/480 VAC |
| Amperage Rating | : | 20 A |
| Number of Poles | : | 4 |
| Number of Wires | : | 5 |
| Color | : | White |
- NO 10-32 multiple drive terminal screws (slotted, Phillips, Robertson)
- Backwired terminations for ease of installation
Instruction/Installation Manual
VIDEO LINK
