nVent HOFFMAN A1212CH
Hoffman A1212CH Junction Box, 12 in H x 12 in W x 6 in D, Continuous Hinged/Screw Clamp Cover, NEMA 12/13/IP65 NEMA Rating, Steel
- Manufacturer Name: nVent
- MPN: A1212CH
- Brand Name: nVent HOFFMAN
- UPC: 783510548902
- FEPN: A1212CH HE
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
This easy-to-open, continuous hinge enclosure features screw-down clamps for secure closure and can be used in a wide variety of applications.
Hoffman Junction Box, Series: A51CH, 12 in Height, 12 in Width, 6 in Depth, NEMA 12/13/IP65 NEMA Rating, Continuous Hinged/Screw Clamp Cover, 10.75 x 10.88 in Panel, Wall Mounting, Steel, Polyester Powder Painted, Gray
| Color | : | Gray |
| Finish | : | Polyester Powder Painted |
| Mounting Type | : | Wall |
| Panel Size | : | 10.75 x 10.88 in |
| Series | : | A51CH |
| Height | : | 12 in |
| Width | : | 12 in |
| Depth | : | 6 in |
| Cover Type | : | Continuous Hinged/Screw Clamp |
| NEMA Rating | : | NEMA 12/13/IP65 |
| Material | : | Steel |
- Seams continuously welded and ground smooth
- Screw-down door clamps
- Bonding provision on door
- External welded on mounting brackets for easy installation
- Oil-resistant gasket
- Weldnuts provided for mounting optional panels and terminal block kits in size 6 x 4 in (152 x 102 mm) and larger
- Continuous hinge
Instruction/Installation Manual
