Panduit® S1/0-14R-X
Panduit® Pan-Lug™ S1/0-14R-X Loose Piece Non-Insulated Tubular Ring Terminal, 1/0 AWG Conductor, 1.6 in L, Beveled/Seamless Barrel, Copper, Metallic
- Manufacturer Name: Panduit
- MPN: S1/0-14R-X
- Brand Name: Panduit®
- UPC: 074983598830
- FEPN: S1/0-14R-X PC
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Panduit® Pan-Lug™ Ring Terminal, Loose Piece Non-Insulated Tubular, Series: S-R Series, Copper Conductor, 1/0 AWG Conductor, 1/4 in Stud, 1.6 in Length, Beveled/Seamless Barrel, 0.58 in L Barrel, Ring Straight Tongue, 0.76 in W x 0.12 in THK Tongue, 35 kVAC, Specifications: 5/8 in L Wire Strip, 5/8 in Mounting Hole, 302 deg F, Copper, Tin Plated, Metallic, 0.76 in W Dimensions
| Barrel Size | : | 0.58 in L |
| Conductor Type | : | Copper |
| Dimensions | : | 0.76 in W |
| Finish | : | Tin Plated |
| Series | : | S-R Series |
| Specifications | : | 5/8 in L Wire Strip, 5/8 in Mounting Hole |
| Stud Size | : | 1/4 in |
| Temperature Rating | : | 302 deg F |
| Tongue Size | : | 0.76 in W x 0.12 in THK |
| Tongue Type | : | Ring Straight |
| Type | : | Loose Piece Non-Insulated Tubular |
| Voltage Rating | : | 35 kVAC |
| Conductor Size | : | 1/0 AWG |
| Length | : | 1.6 in |
| Barrel Type | : | Beveled/Seamless |
| Material | : | Copper |
| Color | : | Metallic |
- Seamless tubular barrel provides a consistent high performance quality crimp
- Round double thick tongue for reliable power applications
- Barrel of terminal internally beveled to provide quick and easy wire insertion
- Inspection window allows visual inspection of proper wire insertion
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
