Color-Keyed® 61975
Color-Keyed® 61975 Bi-Metal Dual Rated Pin Connector With Insulating Cover, 500 kcmil Conductor, 2 in L Pin, Aluminum, Orange
- Manufacturer Name: ABB
- MPN: 61975
- Brand Name: Color-Keyed®
- UPC: 786210619750
- FEPN: 61975 TB
- Min Order Qty: 1
- Quantity Interval: 6
-
Inventory Availability
-
Retail Price:
The Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by T&B®. When using the Color-Keyed® compression system with our Blackburn® line of compression connectors, the installer can count on a reliable, high quality connection.
Color-Keyed® Pin Connector, Bi-Metal Dual Rated, Aluminum/Copper Conductor, 500 kcmil Conductor, Die Code: 107H, 2 in Pin Length, 600 V AC, Specifications: 1-15/16 in L Wire Stripe, 3-3/4 in Body Length after Installing, Tin Plated, Aluminum, 90 deg C, 4.9 in Overall Length, Orange
| Conductor Type | : | Aluminum/Copper |
| Die Code | : | 107H |
| Overall Length | : | 4.9 in |
| Specifications | : | 1-15/16 in L Wire Stripe, 3-3/4 in Body Length after Installing, Tin Plated |
| Temperature Rating | : | 90 deg C |
| Type | : | Bi-Metal Dual Rated |
| Voltage Rating | : | 600 V AC |
| Conductor Size | : | 500 kcmil |
| Pin Length | : | 2 in |
| Material | : | Aluminum |
| Color | : | Orange |
- Converts an aluminum cable into a 2 sizes smaller copper pigtail
- Upgrades connection by eliminating cold flow and oxidation of aluminum
- Barrel prefilled with joint compound
- Aluminum cable size 700 to 750 kcmil
- 500 kcmil copper pigtail wire
- Neoprene insulation
- Aluminum cable, copper pigtail wire
- Electro tin plated finish
