Wiring Device-Kellems SEHBL3
Wiring Device-Kellems Hubbellock® SEHBL3 2-Position Lever Actuated Non-Metallic Standard Foot Mount Switched Enclosure With Receptacle, 600 VAC, 30 A, 3 Poles, Gray
- Manufacturer Name: Hubbell
- MPN: SEHBL3
- Brand Name: Wiring Device-Kellems
- UPC: 783585006000
- FEPN: SEHBL3 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Hubbellock® Switched Enclosure, 2-Position Lever Actuated Non-Metallic Standard Foot Mount, 600 VAC, 30 A, 60 Hz Frequency, 3 Pole, 4X NEMA Rating, -40 to 75 deg C, Composite, Gray
| Frequency Rating | : | 60 Hz |
| Material | : | Composite |
| NEMA Rating | : | 4X |
| Temperature Rating | : | -40 to 75 deg C |
| Type | : | 2-Position Lever Actuated Non-Metallic Standard Foot Mount |
| Voltage Rating | : | 600 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 3 |
| Color | : | Gray |
- Accommodates 30 A, 4-wire Hubbellock® receptacle
- Type 3R rainproof or 12K dust tight
- Molded Valox® resists abuse, corrosion and enhances safety
- Lockable handle meets osha lockout requirements
- Snap action
- 6000 cycles operating
- -40 to 67 deg C without impact
