Wiring Device-Kellems HBL2726
Wiring Device-Kellems HBL2726 3-Phase Flanged Grounding Single Standard Screw Mount Locking Receptacle, 250 VAC, 30 A, 3 Poles, 4 Wires, White
- Manufacturer Name: Hubbell
- MPN: HBL2726
- Brand Name: Wiring Device-Kellems
- UPC: 783585039305
- FEPN: HBL2726 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Hubbell Insulgrip® plugs and connectors continue our long standing tradition of leadership as well as innovative design. The tough nylon body provides impact and chemical resistance commonly needed in the entertainment industry. The durable and powerful offsetting cord grip clamps on individual conductors and outer cord jackets prevent strain on the terminals. It's these and many other features that set Hubbell performance above all others.
Wiring Device-Kellems, HBL2726, Locking Receptacle, 3-Phase Flanged Grounding Single Standard Screw Mount, 250 VAC, 30 A, 3 hp, 3 Pole, 4 Wires, L15-30R NEMA Rating, Industrial Grade, NEMA 4X/12/IP20 Enclosure, -40 to 75 deg C, Screw Terminal, Nylon, White, 3.06 x 3.06 x 2.27 in Dimensions
| Dimensions | : | 3.06 x 3.06 x 2.27 in |
| Enclosure | : | NEMA 4X/12/IP20 |
| Grade | : | Industrial |
| Horsepower | : | 3 hp |
| Material | : | Nylon |
| NEMA Rating | : | L15-30R |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 3-Phase Flanged Grounding Single Standard Screw Mount |
| Voltage Rating | : | 250 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | White |
- Impact resistant thermoplastic construction
- Backwired terminations for ease of installation
