Wiring Device-Kellems HBL2730
Wiring Device-Kellems Twist-Lock® Insulgrip® HBL2730 3-Phase Grounding Standard Screw Mount Locking Receptacle, 480 VAC, 30 A, 3 Poles, 4 Wires, Black
- Manufacturer Name: Hubbell
- MPN: HBL2730
- Brand Name: Wiring Device-Kellems
- UPC: 783585236155
- FEPN: HBL2730 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Twist-Lock® Insulgrip® Locking Receptacle, 3-Phase Grounding Standard Screw Mount, 480 VAC, 30 A, 10 hp, 3 Pole, 4 Wires, L16-30R/WD1/WD5 NEMA Rating, Industrial Grade, IP20 Enclosure, -40 to 75 deg C, Screw Terminal, Nylon, Black, 3.28 x 1.7 x 1.31 in
| Dimensions | : | 3.28 x 1.7 x 1.31 in |
| Enclosure | : | IP20 |
| Grade | : | Industrial |
| Horsepower | : | 10 hp |
| Material | : | Nylon |
| NEMA Rating | : | L16-30R/WD1/WD5 |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 3-Phase Grounding Standard Screw Mount |
| Voltage Rating | : | 480 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | Black |
- High-impact, abuse-resistant nylon face
- Wire restraint recess for both back and side wiring, greatly reduces the possibility of loosening the terminal connection
- Face color coding by voltage facilitates locating and mating of proper devices
- All-brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
