Wiring Device-Kellems HBL2713BK
Wiring Device-Kellems HBL2713BK Heavy Duty Female Grounding Insulated Standard Cord Mount Locking Connector, 125/250 VAC, 30 A, 3 Poles, 4 Wires, Black
- Manufacturer Name: Hubbell
- MPN: HBL2713BK
- Brand Name: Wiring Device-Kellems
- UPC: 783585172330
- FEPN: HBL2713BK HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL2713BK, Locking Connector, Heavy Duty Female Grounding Insulated Standard Cord Mount, 125/250 VAC, 30 A, 2 hp, 3 Pole, 4 Wires, L14-30R NEMA Rating, Industrial Grade, NEMA 4X/12/IP20 Enclosure, 0.35 to 1.15 in Diameter Cord, -40 to 75 deg C, Pressure Screw Terminal, Nylon, Black, 2.33 x 2.33 x 3.86 in Dimensions
| Cord Diameter | : | 0.35 to 1.15 in |
| Dimensions | : | 2.33 x 2.33 x 3.86 in |
| Enclosure | : | NEMA 4X/12/IP20 |
| Grade | : | Industrial |
| Horsepower | : | 2 hp |
| Material | : | Nylon |
| NEMA Rating | : | L14-30R |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Pressure Screw |
| Type | : | Heavy Duty Female Grounding Insulated Standard Cord Mount |
| Voltage Rating | : | 125/250 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | Black |
- Superior cord grip design protects terminations from excess strain
- Clear, funnel shaped wire entry for ease of termination
- Integral dust shield protects wiring chamber from dust or contaminants
Instruction/Installation Manual
