Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by T&B®.
Color-Keyed® Splice Connector, 2-Way, Copper Conductor, 24 AWG to 550 kcmil Conductor, 2.13 in Length, Short Barrel, 600 V, Specifications: 62 Die Code, Copper, Yellow, Tin Plated
| Conductor Type | : | Copper |
| Finish | : | Tin Plated |
| Specifications | : | 62 Die Code |
| Type | : | 2-Way |
| Voltage Rating | : | 600 V |
| Conductor Size | : | 24 AWG to 550 kcmil |
| Length | : | 2.13 in |
| Barrel Type | : | Short |
| Material | : | Copper |
| Color | : | Yellow |
- 2-way high conductivity connectors provide high pullout values
- Easy-to insulate and provide a low resistance connection of high quality and low installed cost
- Color coded for correct matching of installing die and connector
- 35 kV voltage rating
- 550/24 = 222 kcmil, 4/0 Weld, 133/.0399, 259/.0286, 637/.0183 wire size flex
