Wiring Device-Kellems HBL2620
Wiring Device-Kellems HBL2620 HBL® 1-Phase Grounding Heavy Duty Single Screw Mount Locking Receptacle, 250 VAC, 30 A, 2 Poles, 3 Wires, Black
- Manufacturer Name: Hubbell
- MPN: HBL2620
- Brand Name: Wiring Device-Kellems
- UPC: 783585235998
- FEPN: HBL2620 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL2620, Locking Receptacle, 1-Phase Grounding Heavy Duty Single Screw Mount, Series: HBL®, 250 VAC, 30 A, 2 hp, 2 Pole, 3 Wires, L6-30R NEMA Rating, Industrial Grade, -40 to 75 deg C, Screw Terminal, Nylon, Black, 3.28 x 1.7 x 1.31 in Dimensions
| Dimensions | : | 3.28 x 1.7 x 1.31 in |
| Grade | : | Industrial |
| Horsepower | : | 2 hp |
| Material | : | Nylon |
| NEMA Rating | : | L6-30R |
| Series | : | HBL® |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 1-Phase Grounding Heavy Duty Single Screw Mount |
| Voltage Rating | : | 250 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | Black |
- Wire restraint recess for both back and side wiring, greatly reduces the possibility of loosening the terminal connection
- Face color coding by voltage facilitates locating and mating of proper devices
- All-brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
