nVent HOFFMAN CSD24248
nVent HOFFMAN CONCEPT™ CSD24248 CW1 1-Door Enclosure, 24 in L x 24 in W x 8 in D, NEMA 4/12 NEMA Rating, Steel
- Manufacturer Name: nVent
- MPN: CSD24248
- Brand Name: nVent HOFFMAN
- UPC: 783510774608
- FEPN: CSD24248 HE
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Concept enclosures are ideal for machine control applications. With streamlined styling, flush quarter-turn latches and an attractive, durable finish.
nVent HOFFMAN CONCEPT™ Enclosure, 1-Door, Series: CW1, 24 in Length, 24 in Width, 8 in Depth, NEMA 4/12, Concealed Hinged Cover, 22.2 in W x 22.2 in H Panel, Lock: Quarter Turn Latch, Wall Mount, Steel, Polyester Powder Painted, Gray
| Color | : | Gray |
| Cover Type | : | Concealed Hinged |
| Finish | : | Polyester Powder Painted |
| Lock | : | Quarter Turn Latch |
| Mounting Type | : | Wall |
| Panel Size | : | 22.2 in W x 22.2 in H |
| Series | : | CW1 |
| Type | : | 1-Door |
| Length | : | 24 in |
| Width | : | 24 in |
| Depth | : | 8 in |
| NEMA Rating | : | NEMA 4/12 |
| Material | : | Steel |
- Streamlined styling, flush quarter-turn latches and an attractive, durable finish
- Seams continuously welded and ground smooth
- Corner formed door
- Simple easy-to-remove and install hinge pins with built-in captivation clip
- High-torque threadless studs and fasteners on door
- External formed body flange
- Door opens 210 deg
- Removable door with hidden hinges for clean, aesthetic appearance
- Seamless foam in place gasket
- Door alignment device on doors wider than 30 in
- Four hinges on 60 in high enclosures
- Grounding stud on body, bonding provision on door
- Installation instructions provided
- Minimum-width body flange provides maximum door opening (210 deg )
Instruction/Installation Manual
