Panduit® Pan-Lug™ LCB6-14-L 1-Hole Compression Connector Lug, 6 AWG Copper Conductor, Die Code: P24, 1/4 in Stud, Tin Plated Copper

  • Manufacturer Name: Panduit
  • MPN: LCB6-14-L
  • Brand Name: Panduit®
  • UPC: 074983901791
  • FEPN: LCB6-14-L PC
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Panduit® Pan-Lug™ Compression Connector Lug, 1-Hole, Series: LCB, Copper Conductor, 6 AWG Conductor, Die Code: P24, 35 kV, 1/4 in Stud, Standard/Straight Tongue, 0.48 in W x 0.08 in THK Tongue, 1.93 in Overall Length, Long Barrel, 1.07 in L Barrel, 1-1/4 in Mounting Hole, Tin Plated Copper, Blue

Barrel Size       :      1.07 in L
Barrel Type       :      Long without Inspection Window
Color       :      Blue
Mounting Hole Size       :      1-1/4 in
Overall Length       :      1.93 in
Series       :      LCB
Tongue Size       :      0.48 in W x 0.08 in THK
Tongue Type       :      Standard/Straight
Type       :      1-Hole
Voltage Rating       :      35 kV
Conductor Size       :      6 AWG
Conductor Type       :      Copper
Die Code       :      P24
Stud Size       :      1/4 in
Material       :      Tin Plated Copper
  • The long barrel maximizes the number of crimps and provides premium wire pullout strength and performance
  • color-coded barrel marked with Panduit® and specified competitor die index numbers for proper crimp die selection
  • Enclosed barrel prevents corrosive material from entering barrel when used in harsh environment
  • Tin-plated to inhibit corrosion
  • Consult cable manufacturer for voltage stress relief instructions with application greater than 2000 V
  • The generously beveled wire entry prevents bent back strands when inserting the conductor into the barrel
  • pdfFull Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCB6-14-L_Full_Engineering_Drawing.pdf
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCC8-10AW-L_Installation_Manual.pdf
  • pdfTechnical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCC8-10AW-L_Technical_Bulletin.pdf
  • videoVIDEO LINK https://www.panduit.com/content/dam/panduit/en/products/media/7/77/277/5277/110185277.mp4
