Blackburn® is a complete and reliable line of overhead, grounding, mechanical and compression connectors that respond to a broad range of construction needs.
Color-Keyed® Compression Lug, 2-Hole, Series: CTL, Flexible/Stranded Copper Conductor, 500 kcmil Conductor, 35 kV, 1/2 in Stud, Straight Tongue, 3 in L x 1-17/32 in W x 7/32 in THK Tongue, 5 in Overall Length, Short/Standard Barrel, 1-3/8 in L Barrel, Specifications: 1-3/4 in Hole Spacing, Tin Plated, Copper, Brown
| Barrel Size | : | 1-3/8 in L |
| Barrel Type | : | Short/Standard |
| Color | : | Brown |
| Overall Length | : | 5 in |
| Series | : | CTL |
| Specifications | : | 1-3/4 in Hole Spacing, Tin Plated |
| Tongue Size | : | 3 in L x 1-17/32 in W x 7/32 in THK |
| Tongue Type | : | Straight |
| Type | : | 2-Hole |
| Voltage Rating | : | 35 kV |
| Conductor Size | : | 500 kcmil |
| Conductor Type | : | Flexible/Stranded Copper |
| Stud Size | : | 1/2 in |
| Material | : | Copper |
- For use with copper conductor AWG, stranded, flexible cable, welding cable and portable cord
- Made of high conductivity seamless copper tubing
- Tin plated for corrosion-resistance
- Specially chamfered barrel for ease of installation
- Color coded for matching die identification
- Can be used for medium voltage application up to 35 kV provided proper insulation techniques are used
- Short barrel connectors designed for regular duty applications
