Wiring Device-Kellems HBL2823SW
Wiring Device-Kellems Twist-Lock® HBL2823SW 3-Phase Grounding Shrouded Watertight Locking Connector, 277Y/480 VAC, 30 A, 4 Poles, 5 Wires, Black/White
- Manufacturer Name: Hubbell
- MPN: HBL2823SW
- Brand Name: Wiring Device-Kellems
- UPC: 783585456676
- FEPN: HBL2823SW HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Twist-Lock® Locking Connector, 3-Phase Grounding Shrouded Watertight, 277Y/480 VAC, 30 A, 10 hp, 4 Pole, 5 Wires, L21-30R/L22-30R NEMA Rating, NEMA 4X/12 Enclosure, 0.35 to 1.15 in Diameter Cord, Screw Terminal, Thermoplastic, Black/White, 4.38 x 2.75 x 2.75 in
| Cord Diameter | : | 0.35 to 1.15 in |
| Dimensions | : | 4.38 x 2.75 x 2.75 in |
| Enclosure | : | NEMA 4X/12 |
| Horsepower | : | 10 hp |
| Material | : | Thermoplastic |
| NEMA Rating | : | L21-30R/L22-30R |
| Terminal Type | : | Screw |
| Type | : | 3-Phase Grounding Shrouded Watertight |
| Voltage Rating | : | 277Y/480 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 4 |
| Number of Wires | : | 5 |
| Color | : | Black/White |
- Closure cap is included for environmental seal when device is not in use
- One piece, engineered thermoplastic housing is impact resistant for heavy duty industrial environments
- Superior cord grip design for flat cable protects terminations from excess strain
- UL Type 4X environmental seal protects connection while in use
- Impact resistant shroud protects blades against bending and breaking
- Reduces exposure to arcing when connecting or disconnecting under load
