Wiring Device-Kellems HBL2416
Wiring Device-Kellems Twist-Lock® Insulgrip® HBL2416 1-Phase Flanged Single Screw Mount Locking Receptacle, 125/250 VAC, 20 A, 3 Poles, 4 Wires, White
- Manufacturer Name: Hubbell
- MPN: HBL2416
- Brand Name: Wiring Device-Kellems
- UPC: 783585038186
- FEPN: HBL2416 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Twist-Lock® Insulgrip® Locking Receptacle, 1-Phase Flanged Single Screw Mount, 125/250 VAC, 20 A, 2 hp, 3 Pole, 4 Wires, L14-20R NEMA Rating, -40 to 75 deg C, Screw Terminal, Nylon, White, 3.06 x 3.06 x 2.27 in
| Dimensions | : | 3.06 x 3.06 x 2.27 in |
| Horsepower | : | 2 hp |
| Material | : | Nylon |
| NEMA Rating | : | L14-20R |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 1-Phase Flanged Single Screw Mount |
| Voltage Rating | : | 125/250 VAC |
| Amperage Rating | : | 20 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | White |
- Withstands 2000 VAC dielectric voltage
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise
- #8-32 brass terminal and ground screw
- 12 AWG terminal accommodation
- Certified for current interrupting at full rated current interrupting
- Nickel plated brass round head screws mounting screw material
