Wiring Device-Kellems PFBRCBRA
Wiring Device-Kellems PFBRCBRA Flush - S1 Standard Molded Non-Metallic Replacement Cover Assembly, 7 in Dia, 0.44 in D, Aluminum
- Manufacturer Name: Hubbell
- MPN: PFBRCBRA
- Brand Name: Wiring Device-Kellems
- UPC: 783585342542
- FEPN: PFBRCBRA HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, PFBRCBRA, Cover Assembly, Standard Molded Non-Metallic Replacement, Series: Flush - S1, 3 Outlets, 2 Knockouts, 1/2 in Knockout, 7 in Diameter, 0.44 in Depth, 0.51 in Thickness, Round Shape, Surface Mounting, Aluminum, Painted, Brown
| Color | : | Brown |
| Finish | : | Painted |
| Knockout Size | : | 1/2 in |
| Mounting Type | : | Surface |
| Number of Knockouts | : | 2 |
| Number of Outlets | : | 3 |
| Series | : | Flush - S1 |
| Shape | : | Round |
| Thickness | : | 0.51 in |
| Type | : | Standard Molded Non-Metallic Replacement |
| Diameter | : | 7 in |
| Depth | : | 0.44 in |
| Material | : | Aluminum |
- Hinged doors open 180 deg flush to the carpet flange or tile
- Locking studs allow each door to be secured independently
- Die-cast aluminum cover construction for enhanced durability
- For use in 1, 1.5, 2, 3-gang or 4 hr rated unprotected reinforced concrete floors or in 1, 2 or 3-gang hr rated floors employing steel floor units and concrete topping (D900 series design) fire rating
- 2-1/4 in THK floor range (over metal deck) to 7 in (57.2 to 117.8)
- UL installation spacing minimum of 2 ft on centers and not more than one unit per 65 sq-ft of floor area in each span
- Low voltage jack knockout only
- Painted cast aluminum/solid brass, brushed and lacquered carpet flange material
- Engineered flame retardant thermoplastic UL-94 V-0 flammability rating
- 3-gang in Dia cored hole
- Top Service Fitting with Prewired 20A Duplex Receptacle
- 2-Installed Cat 6 Hubbell Xcelerator Jacks
Line Drawing
