Panduit® JN218-216-C
Panduit® Pan-Term® JN218-216-C JN Series Insulated Wire Joint, 600 VAC, 22 to 16 AWG Wire, 0.78 in L, Brass
- Manufacturer Name: Panduit
- MPN: JN218-216-C
- Brand Name: Panduit®
- UPC: 074983840007
- FEPN: JN218-216-C PC
- Min Order Qty: 100
- Quantity Interval: 100
-
Inventory Availability
-
Retail Price:
Panduit® Pan-Term® Wire Joint, Insulated, Series: JN Series, 600 VAC, 22 to 16 AWG Wire, 0.78 in Length, 7/16 in Wire Strip Length, 221 deg F, For Use With: CT-1550, CT-1551 and CT-2500 Crimping Tool, Specifications: 0.27 in Dia Maximum Insulation, 221 deg F, Brass, Clear, Tin Plated, 0.12 in ID x 0.21 in OD Dimensions
| Color | : | Clear |
| Dimensions | : | 0.12 in ID x 0.21 in OD |
| Finish | : | Tin Plated |
| Series | : | JN Series |
| Specifications | : | 0.27 in Dia Maximum Insulation, 221 deg F |
| Suitable For Use With | : | CT-1550, CT-1551 and CT-2500 Crimping Tool |
| Temperature Rating | : | 221 deg F |
| Type | : | Insulated |
| Wire Strip Length | : | 7/16 in |
| Voltage Rating | : | 600 VAC |
| Wire Size | : | 22 to 16 AWG |
| Length | : | 0.78 in |
| Material | : | Brass |
- Large barrel, designed to accommodate from 1 to 7 wires with just one crimp
- Accommodates multiple wire sizes in varying combinations
- Barrel of terminal internally beveled to provide quick and easy wire insertion
