Wiring Device-Kellems HBL2326
Wiring Device-Kellems Twist-Lock® Insulgrip® HBL2326 1-Phase Flanged Grounding Single Standard Screw Mount Locking Receptacle, 250 VAC, 20 A, 2 Poles, 3 Wires, White
- Manufacturer Name: Hubbell
- MPN: HBL2326
- Brand Name: Wiring Device-Kellems
- UPC: 783585037875
- FEPN: HBL2326 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Twist-Lock® Insulgrip® Locking Receptacle, 1-Phase Flanged Grounding Single Standard Screw Mount, 250 VAC, 20 A, 2 hp, 2 Pole, 3 Wires, L6-20R NEMA Rating, Industrial Grade, -40 to 75 deg C, Screw Terminal, Nylon, White, 2.88 x 2.88 x 2.09 in
| Dimensions | : | 2.88 x 2.88 x 2.09 in |
| Grade | : | Industrial |
| Horsepower | : | 2 hp |
| Material | : | Nylon |
| NEMA Rating | : | L6-20R |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 1-Phase Flanged Grounding Single Standard Screw Mount |
| Voltage Rating | : | 250 VAC |
| Amperage Rating | : | 20 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | White |
- NO 10-32 multiple drive terminal screws (slotted, Phillips, Robertson)
- Backwired terminations for ease of installation
Instruction/Installation Manual
VIDEO LINK
