nVent HOFFMAN E1PBG
nVent HOFFMAN E1PBG PB1 Pushbutton Enclosure, 3-1/2 in L x 3-1/4 in W x 2-3/4 in D, 1 Outlets, NEMA 12/IP65 NEMA Rating, Steel
- Manufacturer Name: nVent
- MPN: E1PBG
- Brand Name: nVent HOFFMAN
- UPC: 783510579302
- FEPN: E1PBG HE
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
nVent HOFFMAN Pushbutton Enclosure, Series: PB1, 3-1/2 in Length, 3-1/4 in Width, 2-3/4 in Depth, NEMA 12/IP65, Hinged Cover, 1 Outlets, Wall Mount, Steel, ANSI 61 Polyester Powder Painted, Gray
| Color | : | Gray |
| Cover Type | : | Hinged |
| Finish | : | ANSI 61 Polyester Powder Painted |
| Mounting Type | : | Wall |
| Series | : | PB1 |
| Length | : | 3-1/2 in |
| Width | : | 3-1/4 in |
| Depth | : | 2-3/4 in |
| Number of Outlets | : | 1 |
| NEMA Rating | : | NEMA 12/IP65 |
| Material | : | Steel |
- Seams continuously welded and ground smooth
- Captivated cover screws thread into sealed wells
- Grounding nut in body of enclosure
- Bonding provision on cover
- Oil resistant gasket
- Factory stamped 4-way pushbutton holes
- Enclosures with more than one column of pushbutton holes have internal detachable hinge to hold cover open during wiring, yet permit immediate removal
- External wall mounting brackets
- 16 or 14 ga steel
- These pushbutton enclosures are designed to hold 30.5 mm or 22.5 mm pushbuttons and switches
