Pass & Seymour® PT5262AW
Send Print
  1. pin-int

Pass & Seymour® PT5262AW

Pass & Seymour® PT5262AW 3-Phase Duplex Extra Heavy Duty Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, White

  • Manufacturer Name: Legrand
  • MPN: PT5262AW
  • Brand Name: Pass & Seymour®
  • UPC: 785007860283
  • FEPN: PT5262AW PS
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Pass & Seymour® Straight Blade Receptacle, 3-Phase Duplex Extra Heavy Duty, 125 VAC, 15 A, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Commercial Grade, -40 to 60 deg C, Pigtail Lead Terminal, Thermoplastic, White, 5 in H x 2 in W x 1.43 in D Dimensions

Dimensions       :      5 in H x 2 in W x 1.43 in D
Grade       :      Commercial
Material       :      Thermoplastic
NEMA Rating       :      NEMA 5-15R
Temperature Rating       :      -40 to 60 deg C
Terminal Type       :      Pigtail Lead
Type       :      3-Phase Duplex Extra Heavy Duty
Voltage Rating       :      125 VAC
Amperage Rating       :      15 A
Number of Poles       :      2
Number of Wires       :      3
Color       :      White
  • Plated steel wrap strap design for maximum durability and corrosion-resistance
  • No exposed terminals create a finger safe application before, during and after installation
  • Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections
  • Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL listed, finger safe housing
  • Crimped and welded contacts
  • Large brass contacts snugly terminate on device blade terminals
  • Pre-stripped connector leads fasten to conductors, easier than standard pigtails
  • Auto-ground clip assures positive ground
  • 0.036 in thick, brass, triple-wipe power contacts for lasting retention
  • For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here
  • Temperature Rise, Maximum 30 deg C temperature rise at full-rated current after 50 cycles of overload at 150 Percent of rated current with direct current
  • Operating Temperature, Maximum continuous +60 deg C, minimum -40 deg C without impact
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT5262A_Specification_Sheet.pdf
  • pdfOwners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT5262A_User_Manual.pdf
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT8200BK_Installation_Manual.pdf
  • videoVIDEO LINK http://www.youtube.com/watch?v=_SjD8max4i181
