Wiring Device-Kellems HBL2320
Wiring Device-Kellems Twist-Lock® HBL2320 1-Phase Grounding Heavy Duty Single Screw Mount Locking Receptacle, 250 VAC, 20 A, 2 Poles, 3 Wires, Black
- Manufacturer Name: Hubbell
- MPN: HBL2320
- Brand Name: Wiring Device-Kellems
- UPC: 783585235585
- FEPN: HBL2320 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Twist-Lock® Locking Receptacle, 1-Phase Grounding Heavy Duty Single Screw Mount, 250 VAC, 20 A, 2 hp, 2 Pole, 3 Wires, L6-20R NEMA Rating, Industrial Grade, -40 to 75 deg C, Screw Terminal, Nylon, Black, 3.28 x 1.7 x 1.23 in
| Dimensions | : | 3.28 x 1.7 x 1.23 in |
| Grade | : | Industrial |
| Horsepower | : | 2 hp |
| Material | : | Nylon |
| NEMA Rating | : | L6-20R |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 1-Phase Grounding Heavy Duty Single Screw Mount |
| Voltage Rating | : | 250 VAC |
| Amperage Rating | : | 20 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | Black |
- Withstands 2000 VAC dielectric voltage
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise
- #10-32 brass (white finish on neutral screw when used) multi-drive terminal screw
- #10-32 brass ground screw
- Certified for current interrupting at full rated current interrupting
- 14 to 8 AWG copper terminal accommodation
