Wiring Device-Kellems HBL26419
Wiring Device-Kellems HBL26419 HBL® 3-Phase Heavy Duty Grounding Cord Mount Locking Plug, 600 VAC, 60 A, 3 Poles, 4 Wires, Yellow
- Manufacturer Name: Hubbell
- MPN: HBL26419
- Brand Name: Wiring Device-Kellems
- UPC: 783585017327
- FEPN: HBL26419 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL26419, Locking Plug, 3-Phase Heavy Duty Grounding Cord Mount, Series: HBL®, 600 VAC, 60 A, 3 Pole, 4 Wires, Industrial Grade, IP30 Enclosure, 0.875 to 1.48 in Diameter Cord, -40 to 75 deg C, Pressure Screw Terminal, Nylon, Yellow, 3.03 x 3.03 x 5.9 in Dimensions
| Cord Diameter | : | 0.875 to 1.48 in |
| Dimensions | : | 3.03 x 3.03 x 5.9 in |
| Enclosure | : | IP30 |
| Grade | : | Industrial |
| Material | : | Nylon |
| Series | : | HBL® |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Pressure Screw |
| Type | : | 3-Phase Heavy Duty Grounding Cord Mount |
| Voltage Rating | : | 600 VAC |
| Amperage Rating | : | 60 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | Yellow |
- Molded-in male contacts are resistant to damage and provide a consistently positive connection
- Insulated, color coded metallic housing enhances safety and abuse resistance
- Box terminals in conjunction with stainless steel terminal screws provide maximum termination strength and dependability
Instruction/Installation Manual
