Wiring Device-Kellems HBL9333
Wiring Device-Kellems HBL9333 1-Phase Angled Heavy Duty Male Non-Grounding Cord Mount Straight Blade Plug, 125/250 VAC, 30 A, 3 Poles, 3 Wires, Black
- Manufacturer Name: Hubbell
- MPN: HBL9333
- Brand Name: Wiring Device-Kellems
- UPC: 783585015422
- FEPN: HBL9333 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Straight Blade Plug, 1-Phase Angled Heavy Duty Male Non-Grounding Cord Mount, 125/250 VAC, 30 A, 2 hp, 3 Pole, 3 Wires, 10-30P NEMA Rating, Commercial/Industrial Grade, IP20 Enclosure, 0.625 to 1.187 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Thermoplastic/Composite, Black, 4.34 x 2.75 x 1.88 in
| Cord Diameter | : | 0.625 to 1.187 in |
| Dimensions | : | 4.34 x 2.75 x 1.88 in |
| Enclosure | : | IP20 |
| Grade | : | Commercial/Industrial |
| Horsepower | : | 2 hp |
| Material | : | Thermoplastic/Composite |
| NEMA Rating | : | 10-30P |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 1-Phase Angled Heavy Duty Male Non-Grounding Cord Mount |
| Voltage Rating | : | 125/250 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 3 |
| Color | : | Black |
- Four position assembly
