EATON CL230
EATON CL230 Type CL Classified Replacement Thermal Magnetic Circuit Breaker, 120/240 VAC, 30 A, 10 kAIC Interrupt, 2 Poles, Common Trip
- Manufacturer Name: Eaton
- MPN: CL230
- Brand Name: EATON
- UPC: 786676011655
- FEPN: CL230 EC
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
EATON UL classified replacement circuit breakers are available in both 3/4 in type CHQ and 1 in type CL, 1 and 2-pole configurations. these breakers are classified as direct replacements by Underwriters Laboratories.
EATON Replacement Thermal Magnetic Circuit Breaker, Type CL Classified, 120/240 VAC, 30 A, 10 kAIC Interrupt, Common Trip, 2 Pole, 1 ph, 14 to 4 AWG Copper/Aluminum Wire, Plug-On Mount, 60 to 75 deg C, 3 in L x 2 in W x 3 in H
| Dimensions | : | 3 in L x 2 in W x 3 in H |
| Mounting Type | : | Plug-On |
| Phase | : | 1 |
| Temperature Rating | : | 60 to 75 deg C |
| Type | : | Type CL Classified |
| Wire Size | : | 14 to 4 AWG Copper/Aluminum |
| Voltage Rating | : | 120/240 VAC |
| Amperage Rating | : | 30 A |
| Interrupt Rating | : | 10 kAIC |
| Number of Poles | : | 2 |
| Trip Type | : | Common |
- Common trip requires (2) 1 in space
- 14 to 4 AWG copper aluminum wire range
- 1 in classified replacement breaker
