Wiring Device-Kellems WP1
Send Print
  1. pin-int

Wiring Device-Kellems WP1

Wiring Device-Kellems WP1 Self-Closing Weatherproof Molded Outlet Box Cover, 4.56 in L x 2.84 in W x 1.09 in D, Polyester/Thermoplastic

  • Manufacturer Name: Hubbell
  • MPN: WP1
  • Brand Name: Wiring Device-Kellems
  • UPC: 783585392271
  • FEPN: WP1 HW
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Wiring Device-Kellems, WP1, Outlet Box Cover, Self-Closing Weatherproof Molded, 1 Outlets, 1 Gangs, 4.56 in Length, 2.84 in Width, 1.09 in Depth, Rectangular Shape, -40 to 85 deg C, Vertical Mounting, Surface FS/FD/Threaded Mounting, Polyester/Thermoplastic, Smooth, Gray

Color       :      Gray
Finish       :      Smooth
Mounting Orientation       :      Vertical
Mounting Type       :      Surface FS/FD/Threaded
Number of Gangs       :      1
Number of Outlets       :      1
Shape       :      Rectangular
Temperature Rating       :      -40 to 85 deg C
Type       :      Self-Closing Weatherproof Molded
Length       :      4.56 in
Width       :      2.84 in
Depth       :      1.09 in
Material       :      Polyester/Thermoplastic
  • Used with Single Receptacles with Face Diameter 1.40 in (35.6)
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1fc935b46f6f2a1b61350078e0ed69f283eae13ad7a68d9c8bbf3322cd0b2726.pdf
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_57198d1025e7740a563815a43a27cfcabf7ab1616e6f0c9722f67be1f2b60208.pdf
  • pdfLine Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_98e61c869b7cc5cac50299e63467357e698f1e0dcc67b9cffc224276ea079c2f.pdf
