Wiring Device-Kellems HBL20445B
Wiring Device-Kellems Hubbellock® HBL20445B 3-Phase Grounding Heavy Duty Male Cord Mount Locking Plug, 480 VAC, 30 A, 3 Poles, 4 Wires, Black/White
- Manufacturer Name: Hubbell
- MPN: HBL20445B
- Brand Name: Wiring Device-Kellems
- UPC: 783585017266
- FEPN: HBL20445B HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Hubbellock® Locking Plug, 3-Phase Grounding Heavy Duty Male Cord Mount, 480 VAC, 30 A, 3 Pole, 4 Wires, Industrial Grade, 0.63 to 1.2 in Diameter Cord, -40 to 75 deg C, Pressure Screw Terminal, Nylon, Black/White, 2.33 x 0.94 x 5.63 in
| Cord Diameter | : | 0.63 to 1.2 in |
| Dimensions | : | 2.33 x 0.94 x 5.63 in |
| Grade | : | Industrial |
| Material | : | Nylon |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Pressure Screw |
| Type | : | 3-Phase Grounding Heavy Duty Male Cord Mount |
| Voltage Rating | : | 480 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 3 |
| Number of Wires | : | 4 |
| Color | : | Black/White |
- Black thermoset blade holder
- Glass reinforced PET cord clamp
- Brass blade
- Copper lug terminals with steel set screws terminal screw and ground screw
- Stainless steel, multi-drive cord clamp screw, body holding screw
- Withstands 2000 VAC dielectric voltage
- Certified for current interrupting at full rated current
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise
- Round portable service cords of diameters commensurate with the device rating as defined in UL standard 62, CSA C22.2 No. 49 cord accommodation
- 10 AWG terminal accommodation
- IP20 moisture resistance
- Molded male contacts are resistant to damage and provide a consistently positive connection
- Insulated non-metallic housing enhances safety and abuse resistance
- Box terminals in conjunction with screws with pressure pads provide maximum termination strength and dependability
- Three-piece clamp assembly provides maximum strain relief and protects against entry of moisture and dust
- Auto ejects improperly made connection
Line Drawing
