The XR series terminal block relays are ideal for applications that require a high switching capacity and long electrical service life. the relays are plug-in interfaces that connect to basic terminal blocks. the XR series uses screw or spring cage technology, as well as offers quick system wiring, superior safety features, clear labeling and a high level of modularity.
EATON Terminal Block Relay, Standard, Series: XR Series, 6 A, 120 VAC, 110 VDC Coil, 1PDT Contact Form, 1 Pole, DIN Rail Mounting, Screw Terminal, LED Display, IP67 Enclosure, -4 to 140 deg F, 3.15 in L x 0.24 in W x 3.7 in H Dimensions
| Dimensions | : | 3.15 in L x 0.24 in W x 3.7 in H |
| Display Type | : | LED |
| Enclosure Type | : | IP67 |
| Mounting Type | : | DIN Rail |
| Number of Poles | : | 1 |
| Series | : | XR Series |
| Temperature Rating | : | -4 to 140 deg F |
| Terminal Type | : | Screw |
| Type | : | Standard |
| Amperage Rating | : | 6 A |
| Contact Form | : | 1PDT |
| Coil Voltage | : | 120 VAC, 110 VDC |
- Pluggable relay allows for field replacement, 6 A rated current
- Functional plug-in bridges
- Choice of screw connections or spring cage connection
- LED status indication
- Only 6.2 mm W for 1-pole versions, 14 mm W for double pole
- Environmentally friendly, cadmium-free contact material
- For electrical isolation between the input and output circuits, independence of the type of switching current (AC and DC), high short term overload resistance in the event of short circuits or voltage peaks, low switching losses, ease of operation
- AgSnO contact material, bridge rectifier input protection, 10 mA minimum switching current, 120 mW minimum switching power, 100% operating factor rated operating mode
- 12 VDC voltage, 26 to 14 AWG solid rigid and stranded flexible connection, 3.5/3 mA typical input current, 6 ms typical response time, 15 ms typical release time, 250 VAC/VDC maximum switching voltage, 12 VAC/VDC minimum switching voltage
