Pass & Seymour® 3232TRSW
Pass & Seymour® TradeMaster® 3232TRSW Duplex Tamper-Resistant Self-Grounding Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, White
- Manufacturer Name: Legrand
- MPN: 3232TRSW
- Brand Name: Pass & Seymour®
- UPC: 785007240016
- FEPN: 3232-TRSW PS
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Pass & Seymour® TradeMaster® receptacles combine a traditional look with reliable, time tested operation for any residential application. This receptacle is also outfitted with our Patented automatic shutter system to prevent young children from inserting common objects, such as hairpins or keys. The shutters release when a plug is inserted. Required by the national electrical code (NEC®).
Pass & Seymour® TradeMaster® Self-Grounding Receptacle, Duplex Tamper-Resistant, 125 VAC, 15 A, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, -30 to 60 deg C, Side Wire Terminal, Thermoplastic, White, 1.32 in L x 1 in W x 4.2 in H Dimensions
| Dimensions | : | 1.32 in L x 1 in W x 4.2 in H |
| Material | : | Thermoplastic |
| NEMA Rating | : | NEMA 5-15R |
| Temperature Rating | : | -30 to 60 deg C |
| Terminal Type | : | Side Wire |
| Type | : | Duplex Tamper-Resistant |
| Voltage Rating | : | 125 VAC |
| Amperage Rating | : | 15 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | White |
- Protects children - Patented shutter system now with black "invisi shutters" that disappear for an invisible effect helps prevent improper insertion of foreign objects
- Low profile face
- Side wire accepts 12 to 14 AWG solid wire
- Markings on strap per UL tamper-resistant requirements
- Traditional contoured face
- Safer and more effective than traditional plastic outlet caps or protection plates
- Extra long strap
- Quick-loop wire looping aid
- Long-term blade retention
- Longer tri-drive screws for easier 12 AWG looping
- Extra large circuit break-off tabs
- Side access push wire release
- Self-grounding models provide automatic ground clip
- Quality Materials, durability, and time-tested design
- Two drive screws anchor strap to back body and face where abrupt removal torque is greatest
